High Speed Side Sealer with Heat Shrink Tunnel

Continuous & Intermittent Motion Style Shrink Wrappers

Our high speed intermittent side sealing machine with heat shrink tunnel is capable of shrink wrapping almost any length of product.

What are the benefits of using a side sealer shrink wrapper?

The side sealer provides automatic transfer of the products from the feed conveyor and sealer through the tunnel, without manual intervention. Other features include:

• Higher wrapping speeds
• Improved productivity
• Reduced film widths possible via continuous motion
• Intermittent motion or continuous motion available

• High Speed Side Sealer with Heat Shrink Tunnel Technical Data

  Side Sealer technical data
  Our side sealer with heat shrink tunnel offers excellent performance as well as value for money. Review the machine technical data:

  	MES 530 Series - Intermittent Motion	MES 530 Series - Intermittent Motion	MES 530 Series - Intermittent Motion
  Model	MES-530	MES-800	MES-950
  Machine Size	1820mm (l) x 1605mm (w) x 1350mm (h)	2240mm (l) x 2250mm (w) x 1480mm (h)	238mm (l) x 2515mm (w) x 1490mm (h)
  End Seal Bar	530mm	800mm	950mm
  Product Size	80-∞mm (l) x 50-420mm (w) x 2-180mm (h)	100-∞mm (l) x 80-600mm (w) x 2-180mm (h)	200-∞mm (l) x 150-820mm (w) x 10-180mm (h)
  Conveyor Speed	10-30 Per Minute	10-30 Per Minute	10-30 Per Minute
  Power Supply	220v Single Phase	220v Single Phase	220v Single Phase
  Power	3kW	4.5kW	5.5kW
  Pneumatic	4 Bar	4 Bar	4 Bar

  	MES S-30A series - Continuous Motion	MES S-30A series - Continuous Motion	MES S-30A series - Continuous Motion
  Model	MES-30A	MES-50A	MES-60A
  Machine Size	2295mm (l) x 1160mm (w) x 1370mm (h)	4100mm (l) x 1610mm (w) x 1370mm (h)	4250mm (l) x 1760mm (w) x 1370mm (h)
  End Seal Bar	380mm	530mm	680mm
  Product Size	80-700mm (l) x 80-230mm (w) x 10-180mm (h)	80-700mm (l) x 80-380mm (w) x 10-180mm (h)	80-700mm (l) x 80-380mm (w) x 5-180mm (h)
  Power	5kW	5kW	5kW
  Pneumatic	4 Bar	4 Bar	4 Bar

  Shrink Tunnel technical data
  Review the MES 61, 62, 63, 64, & 65 Shrink Tunnel technical data:

  	Shrink Tunnel	Shrink Tunnel	Shrink Tunnel	Shrink Tunnel	Shrink Tunnel
  Model	MES-61	MES-62	MES-63	MES-64	MES-65
  Machine Size	1450mm(l) 860mm(w) 1080mm(h)	1700mm(l) 900mm(w) 1160mm(h)	2200mm(l) 1070mm(w) 1230mm(h)	2200mm(l) 1090mm(w) 1230mm(h)	2200m(l) 1250mm(w) 1230mm(h)
  Chamber Size	1100mm (l) 300mm (w) 200mm (h)	1200mm (l) 350mm (w) 280mm (h)	1700mm (l) 440mm (w) 350mm (h)	1700mm (l) 540mm (w) 350mm (h)	1700mm (l) 700mm (w) 350mm (h)
  Product Size	280mm (w)  150mm (h)	300mm (w) 230mm (h)	400mm (w) 300mm (h)	500mm (w) 300mm (h)	650mm (w) 300mm (h)
  Voltage	400v 3 Phase	400v 3 Phase	400v 3 Phase	400v 3 Phase	400v 3 Phase
  Power	11kW	14kW	16kW	18kW	23kW
  Conveyor Speed	0-30 Min	0-30 Min	0-30 Min	0-30 Min	0-30 Min

  Please download our high speed side sealer brochure to view all technical data and machine specification at your leisure.




  Download Machine Brochure

  Side Sealer brochure

What is the wrapping capabilities of a side sealer wrapping machine?

The preferred machine for customers who wish to wrap a range of products at high speed, the side sealer delivers the final wrapped product with a presentation quality finish. Other machine features include:

• Product recipe menu
• Wrapping speeds of up to 120 packs per minute / 7,200 per hour subject to pack size
• Infeed conveyor options
• Up to 1100mm wide sealing bar

Call us today to discuss your requirements and how we can help you improve your shrink packaging efficiency at 01202 870 201

Options available for ME 530 series and MES S-30A series side sealers:

Closing Conveyor, Product Collating, Polyethylene Blades, Bespoke Safety Levels, Alternative PLC’s, Low Film Warning, Line Integration, Stainless Steel (INOX), Opposite Handing.

Options available for MES-61 to MES-65 shrink tunnels:

Close Pitch Rollers, Opposite Handing, Stainless Steel.
